BF Pleat Water Filter

BF high flow filter cartridge is made by diameter 6'' and pleated design with high flow area and contamination removal capacity. This is design helps end user to reduce capital investment, save plant space, easy to change –out and ect, Pullner BF product has various applications on water treatment system.

Features:
Fewer cartridge and less time to assemble.
Commonuse size:40''length cartridge.
The design of aperture change gradually.
Sealing interface design to reduce the risk of bypass.
Large surface area pleated design provide low pressure drop and long service life.
Polypropylene cartridges comply with FAD grade.
Flow rate up to 1300LPM per cartridge.

Application:

Industrial	Municipal water, RO Prefiltration, reclaimed water, coolant, nozzle protection, belier condensate, desalination
Chemical	Quench water, aqueous salt solutions, final products
Petrochemicals	Water flooding ,produced water, enhanced oil recovery, completion fluids, amine sweetening ,final products.
Electronics	RO Prefiltration, process water, deionized water prefiltration.
Food and Beverage	Process and blending water ,bottled water
Pharmaceutical	Process water
Power Plant	Supplementary water, condensation water, coolant.

Specification

Material and Construction:

Filter Medium:	Polypropylene ,Cellulose ,Melt Blown pp
Support:	Polypropylene
End Caps:	Glass Fiber Reinforced Polypropylene
Oring Seal options:	EPDM, NBR, Viton.

Max. Operating Differential Pressure:

Polypropylene:	3.44bar@82 Degree,50psi@180°F
Glass Fiber:	3.44bar@82 Degree,50psi@180°F
Suggestion Flow:	40’’1300LPM

PH	PP	0400	40	G	E	Z
	Material	Micron	LengtK(inch)	Supporting	Seal	Connector
	pp	0010=1	40=40	B=outer belt	B:NBR	ZA=single oring
	GF	0050=5		G=outer cage	S:NBR	ZB=double oring
		0100=10			E:EPDM
		0150=15			F:Viton
		0200=20
		0400=40
		0700=70
		1000=100
