Filter Bag Dust Collector Systems Types:

ln Pulse Jet and Plenum Pulse systems, the dust is collected on the outside of the filter bag and the clean air exits through the inside of the bag. The bag is supported by a wire cage to prevent the bag from collapsing during operation.

In a 'Top Load' system, the bags and cages are installed from the clean air side of the cell plate while with 'Bottom Load' they are installed from the dirty air/hopper side of the unit.

ln Shaker and Reverse-Air cleaning systems the dust is collected on the inside of the filter bag. Since the bag is inflated with the air/dust stream, support cages are not required. The filtered air exits through the outside surface of the bags. Many configurations are available to suit the needs of most dust collectors.

As a professional filter bag manufacturer and supplier, D.King offers a range of bags to fit almost every configuration in the marketplace. Talk to us to learn more!

Filter Bag Media Options:

As a general rule, Pulse Jet and Plenum Pulse cleaning systems utilize needle felt medias, while Shaker and Reverse Air systems use woven medias. Medias are manufactured from a variety of man-made fibers and are selected based on a number of factors including: operating temperature, chemical components in the dust stream, abrasiveness of the dust being handled as well as other characteristics of the particular systems usage. A number of treatments are available to improve dust discharge on the cleaning cycle, improve the filter efficiency of the media, to add flame retardant qualities and other specialized applications.
Custom Size Range: 2 ½" to 48" diameter, all lengths available.

• Aramid
• Copolymer Acrylic
• Cotton Sateen
• Dacron
• Duo Density P.E.
• Fiberglass
• Plain
• PTFE membrane
• Silicon
• Singed
• 10% Teflon B coating

Finishing Treatment Available:

• Acrylic Coated
• Copper and Stainless Steel Ground Wires
• Eggshell
• Flame Retardant
• Glazed
• Napped
• Oleophobic
• Nylon
• PE with blended stainless steel
• Polyester (PE) Woven, Needle felt, Knitted
• Polypropylene (PP)
• Ryton
