Material: Steel Stainless

Structure:

1. End and bottom end caps, material is stainless steel and plastic
2. Inner tube, material is stainless steel
3. Filter medium, material is stainless steel mesh

Feature:

1. Pressure: ≤1.6Mpa
2. Flow rate : 20-60L/min
3. Working medium: hydraulic oil and lubricating oil
4. Loss press: <0.1Mpa
5. Filter material: stainless steel
6. Size: φ30*223~φ30*745
7. The high intensity, long service life, corrosion resistance, temperature range, without material from
8. Big filter area, big flow, porosity, permeability, high carrying capacity, with strong sex (can be repeated cleaning)
9. With size, Z series (type filter) filtering area for Y series (cylindrical) filte area of 2.5-4 times, prolong the cartridge replacement cycles
10. Installation ,removal and clean easily

Application

1. Applicable in metallurgical, petrochemical, machinery manufacturing, paper making, textile, food and medicine, life, and environmental protection, oil, water filtration, involving all industries:
2. Crude oil, fuel oil, petrol, kerosene, diesel oil filter, etc
